10.1" Панелни компютри и HMI — ARM: Raspberry Pi CM4, Raspberry Pi OS, 1280 × 800
Спецификации
- SKU
- CS12800RA4101P
- Нетно тегло
- 1600 g
- Форм-фактор
- Panel
- Процесор
- ARM: Raspberry Pi CM4
- Flash памет
- 16GB
- Външна памет
- 1 TF card slot designed for storage expansion
- Диагонал на екрана
- 10.1"
- Разделителна способност
- 1280*800
- Яркост
- 400 NIT
- Сензорен екран
- Capacitive
- Wi-Fi / Bluetooth
- Depends on the Compute Module 4 selected.
- 4G
- Optional
- Zigbee
- Optional
- USB
- 2 x USB 3.0 Host, 1 x USB OTG
- CAN
- 1 x CAN
- RS232
- 2 x RS232
- RS485
- 2x RS485
- GPIO
- 8 Channels, 4 Input, 4 Output
- Ethernet
- 1x RJ45, 1 Gbps
- Камера
- There is a camera connector compatible with the Raspberry Pi Camera connector (the camera is NOT mounted by default).
- Аудио
- 3.5mm Audio In/Out Connector; Internal 2W Speaker
- Зумер
- Onboard, driven by GPIO
- RTC
- High Accuracy RTC, can work 1 week after power off
- Операционна система
- Raspberry Pi OS
- Входно захранване
- 15~36V DC
- Ток при 15 V
- 0.64A Max
- Консумация
- 9.6W
- Работна температура
- 0°C to +60°C
- Начин на монтаж
- Panel Mounting & VESA
- Цвят на корпуса
- Gray; Black
- Модул Raspberry Pi CM4
- CM4002032 ($100): No WiFi/BT+2GB DDR+32GB eMMC; CM4102016 ($100): WiFi+2GB DDR+16GB eMMC; CM4102032 ($105): WIFI+2GB DDR+32GB eMMC; CM4104016 ($137): WIFI+4GB DDR+16GB eMMC; CM4104032 ($142): WIFI+4GB DDR+32GB eMMC; CM4108032 ($216): WIFI+8GB DDR+32GB eMMC
