15.6" Панелни компютри и HMI — ARM: Raspberry Pi CM4, 1920 × 1080
Спецификации
- SKU
- CS19108RA4156A
- Нетно тегло
- 1600 g
- Размери без стойка
- 374 x 238 x 33 mm
- Форм-фактор
- All-In-One
- Процесор
- ARM: Raspberry Pi CM4
- Постоянна памет
- TF card slot for boot. Internal M.2 NVMe connector for SSD card.
- microSD слот
- For use only with CM4 Lite modules
- Диагонал на екрана
- 15.6"
- Разделителна способност
- 1920*1080
- Яркост
- 350 NIT
- Сензорен екран
- Capacitive
- USB
- 2 x USB 3.0 Host connector, 1Type-C USB Slave connector.
- GPIO / Wiegand
- Raspberry Pi 40-pin GPIO connector.
- HAT конектор
- Standard Raspberry Pi 40-way HAT connector.
- Ethernet
- 1x RJ45, 1 Gbps
- Камера
- Camera on the front panel, NOT mounted by default
- Аудио
- 3.5mm Audio In/Out Connector; Internal 2W Speaker
- Зумер
- Onboard, driven by GPIO
- RTC
- High accuracy internal RTC (keep track of time one week after power off)
- Операционна система
- Android; Raspberry Pi OS
- Входно захранване
- 12V DC
- Консумация
- 10W
- Ток при 12 V
- 700 mA max
- Работна температура
- 0℃~50℃
- Цвят на пластмасовия корпус
- Black
- Модул Raspberry Pi CM4
- CM4002000 ($57): 2GB DDR, no WiFi, or eMMC; CM4002016 ($79): No WiFi/BT+2GB DDR+16GB eMMC; CM4002032 ($100): No WiFi/BT+2GB DDR+32GB eMMC; CM4102000 ($57): WIFI/BT+2GB DDR no eMMC; CM4102016 ($100): WiFi+2GB DDR+16GB eMMC; CM4102032 ($105): WIFI+2GB DDR+32GB eMMC; CM4104016 ($137): WIFI+4GB DDR+16GB eMMC; CM4104032 ($142): WIFI+4GB DDR+32GB eMMC; CM4108032 ($216): WIFI+8GB DDR+32GB eMMC
