5.0" Панелни компютри и HMI — ARM: Raspberry Pi CM4, Raspberry Pi OS, 1280 × 720
Спецификации
- SKU
- CS12720RA4050P
- Нетно тегло
- 310 g
- Форм-фактор
- Panel
- Процесор
- ARM: Raspberry Pi CM4
- Flash памет
- Based on CM4
- Външна памет
- TF (microSD) Card Slot
- Диагонал на екрана
- 5.0″
- Сензорен екран
- Capacitive
- Разделителна способност
- 1280 x 720
- Яркост
- 400 NIT
- Wi-Fi / Bluetooth
- Depends on the Compute Module 4 selected.
- 4G
- Not supported
- Zigbee
- Not supported.
- USB
- 1 x Type-C OTG; 2x USB 2.0 HOST
- CAN
- 1 x CAN
- RS232
- 2 x RS232
- RS485
- 2 x RS485
- GPIO
- Not supported
- Ethernet
- 1x RJ45, 1 Gbps
- Камера
- Supported. Not mounted by default.
- Аудио
- 3.5mm Audio In/Out Connector; Internal 2W Speaker
- Зумер
- Not supported
- RTC
- Yes. High Accuracy RTC with Lithium Button Coin battery (Lithium Battery not included)
- Операционна система
- Raspberry Pi OS
- Входно захранване
- 9V~36V DC
- Консумация
- 6W
- Ток при 12 V
- 500 mA max
- Работна температура
- 0°C to +60°C
- Начин на монтаж
- Panel Mounting & VESA
- Модул Raspberry Pi CM4
- CM4002000 ($57): 2GB DDR, no WiFi, or eMMC; CM4002016 ($79): No WiFi/BT+2GB DDR+16GB eMMC; CM4002032 ($100): No WiFi/BT+2GB DDR+32GB eMMC; CM4102016 ($100): WiFi+2GB DDR+16GB eMMC; CM4102032 ($105): WIFI+2GB DDR+32GB eMMC; CM4104016 ($137): WIFI+4GB DDR+16GB eMMC; CM4104032 ($142): WIFI+4GB DDR+32GB eMMC; CM4108032 ($216): WIFI+8GB DDR+32GB eMMC
