PPC-A53-050

Спецификации

SKU

CS12720-IMX8MP-050P

Нетно тегло

310 g

Форм-фактор

Panel

Процесор

ARM: NXP i.MX8MP

Тактова честота на процесора

NPU 2.3TOPS; Quad Cortex A53, 1.6GHz

Вградена памет (eMMC)

32GB

Оперативна памет

LPDDR4 4GB

Постоянна памет

TF Card, Supports up to 128GB SDHC

SSD

Not supported

Диагонал на екрана

5.0″

Разделителна способност

1280 x 720

Яркост

400 NIT

Сензорен екран

Capacitive

Wi-Fi / Bluetooth

Onboard (Bluetooth is functional on Yocto Linux, but not on Android)

4G

Not supported

Ethernet

1 x RJ45, GbE

HDMI

1 x HDMI-D 2.0 (Micro-HDMI) Out

GPIO

Not supported

RS232

2 x RS232 by deafult (Optional 4 x RS232 at most, include 1 debug port)

RS485

2x RS485

USB

1 x USB 3.0 HOST; 1 x USB Type-C; 1x USB 2.0 HOST

CAN

1 x CAN by default (can be changed to 2 x CAN)

RTC

High accuracy RTC with farad capacitor, can work 1 week after power off (default). High accuracy RTC with lithium coin battery, can work 3 years after power off (optional).

Аудио

3.5mm Audio In/Out Connector; Internal 2W Speaker

Зумер

Onboard, driven by GPIO

Операционна система

Android; Yocto

Консумация

Max brightness, max CPU load: 6.24W; Min brightness, idle: 3W.

Входно захранване

6~36V DC

Ток при 12 V

Max brightness, max CPU load: 0.52A at 12V; Min brightness, idle: 0.25A at 12V.

Работна температура

-20℃ ~ 60℃

Начин на монтаж

VESA, PANEL
