The EPC-A9-097-C (PN CS10768F097E) is a high-quality industrial embedded computer, that features a 9.7-inch LCD with capacitive touchscreen, a quad-core Cortex-A9 processor with 2GB DDR3 RAM and 8GB eMMC Flash, an onboard WiFi and Bluetooth, one 4G antenna, 1Gb Ethernet, 3 USB 2.0 ports, 2 CAN ports, 2 RS232, 3 RS485 ports, 1 HDMI port for a secondary monitor, a SATA-II channel for extra storage, as well as a 3.5mm audio connector.
Specifications
- SKU
- CS10768F097E
- Net weight
- 550 g
- Form-factor
- Embedded
- Display Size (inch.)
- 9.7"
- Touch Screen
- Capacitive
- CPU
- ARM: NXP iMX6Q
- RAM
- 2GB DDR3
- FLASH
- 8GB
- Display resolution
- 1024*768
- Brightness
- 350 NIT
- Bluetooth
- Onboard
- WiFi/BT
- Onboard WiFi
- 4G
- Optional
- HDMI
- 1x HDMI
- SATA
- 1x SATA II
- Ethernet
- 1x LAN 100M Optional; 1x RJ45, 1 Gbps
- USB
- 1x USB 2.0 OTG; 2x USB 2.0 HOST
- GPIO
- 4x Isolated Input, 4 Isolated Output 5~24V (can drive 500mA current)
- RS485
- 3x RS485
- CAN
- 2 x CAN
- RS232
- 2 x RS232
- Buzzer
- Onboard, driven by GPIO
- External storage
- TF (microSD) Card Slot
- Power Input
- 12~36V DC
- Power Consumption
- 7W
- Working Temperature
- -20°C ~ 70°C.
- Operating System
- Android; Ubuntu; Yocto
- Certification
- CE
- Mounting Method
- Embedded Mounting
- GTIN
- 6974174310200
