MER2-2000-19U3M-L

Specifications

Model

MER2-2000-19U3M-L

Product Families

MERCURY2

Resolution

5496×3672

Frame Rate (fps)

19.6

Sensor Manufacturer

Sony

Sensor

1" IMX183 Rolling shutter CMOS

Pixel Size

2.4μm

Размер на сензора (изчислен)от резолюция × стъпка на пиксела

13.19 × 8.81 mm

Диагонал на сензора

15.86 mm

Pixel Bit Depth

8 bit，12 bit

Data Interface

USB3.0

Lens Mount

C，CS

Spectrum

Mono

Pixel Formats

Mono8，Mono12

Signal Noise Ratio

42.08 dB

Exposure Time

Standard: 12μs ~ 1s

Gain

0dB ~ 24dB

Binning

FPGA: 1×1, 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4, Sensor: 1×1, 2×2

Decimation

FPGA: 1×1, 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4

Reverse X/Y

Reverse X/Y

Power Requirement

Power over USB3.0

Power Consumption

2.00 W @ 5 VDC

Operating Temp.

0°C ~ +45°C

Storage Temp.

-20°C ~ +70°C

Operating Humidity

10% ~ 80%

Dimensions (W×H×L)

29 mm × 29 mm × 29 mm (w/o connectors)

Weight

61 g

Conformity

CE, RoHS, FCC, ICES, UKCA, UL, USB3.0 Vision, GenICam
