Vision Components — PCI-E gen2 × 4
Model
- Product Model
- MV-GE2202P
- Type
- Dual ports WX1860 POE Ethernet Adaptors
Performance
- Main chip
- WX1860 chip
Host interface
- Interconnect
- PCI-E gen2 × 4
- Delivery bandwidth
- 860 MB/s (max. transmission bandwidth) 800 MB/s (sustained transmission bandwidth)
Camera interface
- Standard
- IEEE 802.3
- Interface
- RJ45 × 2
- Camera type supported
- GigE industrial camera
- Camera quantity supported
- 2 at most
- Camera connection speed
- 10/100/1000 Mbps
- Stream
- 2
Electrical feature
- Power consumption
- Typ. 2 W (without PoE)
Mechanical
- Dimension
- 181 mm × 126.3 mm × 21.6 mm (7.1" × 5.0" × 0.9")
- Weight
- 190 g (0.4 lb.)
- Temperature
- Working temperature: 0 °C to 60 °C (32 °F to 140 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
- Humidity
- 10% RH to 95% RH (no condensation)
General
- Operating system
- 64-bit Windows 7/10/11, Linux
- Certification
- CE, KC
