Line Laser 3D Camera

Name: Line Laser 3D Camera
Brand: Hikrobot
SKU: MV-DL2125-04P-R

MV-DL2125-04P-RHikrobot

GigE 3D камери

Model

Near field of view: 1000 mm
Far field of view: 2600 mm
Clearance distance (CD): 700 mm
Measurement range (MR): 1000 mm
Detection accuracy: ± 5 mm (standard object)
Detection speed: 3 m/s @ ± 5 mm detection accuracy
Scan frame rate: 1140 fps @ 1 m depth measurement range
Data type: Point cloud data, length/width/height, integral volume, top coordinates, depth image, brightness image
Trigger mode: External trigger, encoder trigger (max. 15 kHz trigger signal supported)
Laser safety class: Class 3B

Data interface: Gigabit Ethernet (1000 Mbit/s)
Digital I/O: 12-pin M12 interface provides I/O, including opto-isolated input × 3 (Line 0/3/6), opto-isolated output × 3 (Line 1/4/7), RS-232 × 1.
Power supply: 12 VDC to 24 VDC
Power consumption: Typ. 19.2 W @ 24 VDC

Dimension: 354.1 mm × 65 mm × 123.4 mm (13.9" × 2.6" × 4.9")
Weight: 1.6 kg (3.5 lb.)
Temperature: Working temperature: 0 °C to 45 °C (32 °F to 113 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity: 20% RH to 85% RH (no condensation)
