Model
- Product Model
- LRS-50-24
- Type
- Power Supply_24V50W
Physical specification
- End A connector
- Terminal block (220 VAC Input)
- End B connector
- Terminal block
- Applicable scenario
- Static
Electrical specification
- Input voltage range
- 85 VAC ~ 264 VAC
- Input AC current
- 1.1 A @ 115 VAC 0.65 A @ 230 VAC
- Output power
- 50 W max
- Output voltage
- 24 V
- Output current
- 0 A ~ 2.09 A
- Over current protection
- > 120% of rated current, hiccup mode, non-latching (auto-recovery)
- Over voltage protection
- Overvoltage protection range: 28.8 V to 33.6 V Protected mode: Turn off the output voltage, restart and restore.
- MTBF
- 200,000 h (Standard: Telcordia SR-332)
Additional information
- Working temperature
- –10 °C to 70 °C (14 °F to 158 °F) (For temperatures above 50 °C, the output load decreases by 2.5% for every degree increase in temperature.)
- Certification
- CE,UL,CCC
- Packaging
- Individual package
